1.4305 (X8CrNiS18-9) Material Data Sheet

Back to category page

1.4305 (X8CrNiS18-9) directly from stock & cut to your required dimensions!

International identifiers
AISI 303, SS 2346, ASTM Type 303, UNS S30300, AFNOR Z8CNF18-09, BS 303S31, BS 303S22, BS EN58M, JIS SUS303, GOST 12X18H10E, GB Y1Cr18Ni9
Scopes

1.4305 alloyed with sulfur is an austenitic chromium-nickel steel. Not resistant to intergranular corrosion! Not to use in acid and chlorine containing environments, because these can cause pitting or crevice corrosion.

The stainless steel type 1.4305 is popularly known as AISI 303.


Main application areas are the automotive industry, mechanical engineering, fittings for medium corrosive stresses, electronic equipment, parts for the food industry.

Characteristics

Weldability:      bad

Machinability:  10 (1 = very bad - 10 = good)

Polishability:    no

Corrosion class:   2 (0 = weak - 5 = good)



Calculate the weight of the required material quickly »

Chemical composition
1.4305
X8CrNiS18-9
CSiMnPSCrMoNiV
min.    0,1517,0 8,0
max.0,101,02,00,0450,3519,0 10,0
1.4305
X8CrNiS18-9
AlCuNNbTiSonstiges
min.
max.   1,00,11
In stock

plate, rolled, solution annealed
flat, forged, solution annealed

StahlblechStahlblock
Advantages of saw cut

The processing with the saw is a mechanical processing of the material, which results in a significantly lower unintended deformation and increased hardness for the existing structure, such as the thermal cutting.

Thus, the machined workpiece has a homogeneous structure even at the edge, which does not change in the continuation of the material.
This circumstance allows immediate finishing of the workpiece with milling or drilling . So it is not necessary to anneal the material or make a similar operation beforehand.

The most important questions and answers about the material 1.4305:

Wie ist die Zugfestigkeit von Werkstoff 1.4305?

Edelstahl 1.4305 hat eine Zugfertigkeit von 500 bis 750 N/mm².

Wie ist die Dichte von Werkstoff 1.4305?

Edelstahl 1.4305 hat bei 20°C eine Dichte von 7,9 kg/dm³.

Wie ist die Härte von Werkstoff 1.4305?

Edelstahl 1.4305 hat eiene Härte von ≤ 230 HB.

Was ist 1.4305 für ein Stahl?

 Edelstahl 1.4305 ist ein austenitischer Chrom-Nickel-Stahl mit zusätzlichem Schwefel.



Do you have any questions?

We are happy to answer your questions and make you an offer for these and other materials. Contact us now for more information.

Heidi Sommer

Your contact person Heidi Sommer+49 (0) 35263-665-33

contact now

Notice: Specifications contained in following data sheet are provided as a description, liability is excluded!
