1.2767 ESU (45NiCrMo16 | X45NiCrMo4) directly from stock & cut to your required dimensions.

International identifiers
45NiCrMo16 | X45NiCrMo4, AISI 6F7 ESR, AFNOR 435 NCD 5, NPW
Scopes

The nickel-alloyed cold work steel 1.2767 ESU has an improved material property due to the electroslag remelting (ESR) process. The ESU guide is used when better material purity, particularly high tensile strength and compressive strength is required. The material 1.2767 ESU (45NiCrMo16) has a high toughness (nickel content), very good through hardenability as well as a high impact resistance and pressure resistance. Working hardness 52-55 HRC. Good polishable and erodible.

The tool steel 1.2767 is suitable for the following application areas: cutlery punching, stamping tools, solid stamping dies and punches, bending tools, pressure bars on press brakes, shear blades for thick cutting material, plastic molds and reinforcements.

Characteristics

annealed max. 262 HB

Machinability: 4 (1 = very bad - 10 = good)



Calculate the weight of the required material quickly »

Chemical composition
1.2767 ESU
45NiCrMo16
X45NiCrMo4
CSiMnPSCrMoNiV
min.0,40,10,15  1,20,153,8
max.0,50,40,450,0250,0201,50,354,30,15
1.2767 ESU
45NiCrMo16
X45NiCrMo4
AlCuNNbTiW
min.
max.0,030,25       0,15
In stock

Flat, forged, annealed

Stahlblock
Advantages of saw cut

The processing with the saw is a mechanical processing of the material, which results in a significantly lower unintended deformation and increased hardness for the existing structure, such as the thermal cutting.

Thus, the machined workpiece has a homogeneous structure even at the edge, which does not change in the continuation of the material.
This circumstance allows immediate finishing of the workpiece with milling or drilling . So it is not necessary to anneal the material or make a similar operation beforehand.
