1.2714 (55NiCrMoV7) directly from stock & cut to your required dimensions!
![[Translate to Englisch:]](/fileadmin/user_upload/produkt-fotos/1.2714_Flachstahl.jpg "[Translate to Englisch:]")
![[Translate to Englisch:]](/fileadmin/user_upload/produkt-fotos/1.2714_Stahlblock.jpg "[Translate to Englisch:]")
Hot work steel or die steel (oil- and air-hardening steels) with good toughness, through hardenability and high compressive strength.
forging and swaging with very large dimensions, hot forming tools, hot shear blades, extrusion tools, punches, tools for forging machines, tool holders, die holders.
1. quenched and tempered ca. 1200 - 1350 N/mm²
2. annealed max. 250 HB
Weldability: no
Machinability: 5 (1 = very bad - 10 = good)
| 1.2714 55NiCrMoV7 | C | Si | Mn | P | S | Cr | Mo | Ni | V |
|---|---|---|---|---|---|---|---|---|---|
| min. | 0,5 | 0,6 | 0,8 | 0,35 | 1,5 | 0,05 | |||
| max. | 0,6 | 0,9 | 1,2 | 0,55 | 1,8 | 0,15 |
Flat, forged, annealed
Flat, forged, quenched and tempered
The processing with the saw is a mechanical processing of the material, which results in a significantly lower unintended deformation and increased hardness for the existing structure, such as the thermal cutting.
Thus, the machined workpiece has a homogeneous structure even at the edge, which does not change in the continuation of the material.
This circumstance allows immediate finishing of the workpiece with milling or drilling . So it is not necessary to anneal the material or make a similar operation beforehand.
Do you have any questions?
We are happy to answer your questions and make you an offer for these and other materials. Contact us now for more information.
Your contact person Andreas Blachowiak+49 (0) 35263-665-37blachowiak@stahlportal.com
Notice: Specifications contained in following data sheet are provided as a description, liability is excluded!
