1.0601 (C60) | 1.1221 (C60E) Material data sheet
The non-alloy structural steel 1.0601 / C60E is ideal for use in mechanical engineering, automotive construction, and tool manufacturing. Thanks to its high strength and excellent machinability, this material is perfectly suited for components subjected to increased mechanical demands.
C60 is difficult to weld and is not suitable for welded structures . As a rule, the material should be preheated to 250 ° C to be error-free welded.
| 1.0601 C60 1.1221 C60E | C | Si | Mn | P | S | Cr | Mo | Ni | V |
|---|---|---|---|---|---|---|---|---|---|
| C60 min. C60E min. | 0,57 0,57 | 0,6 0,6 | |||||||
| C60 max. C60E max. | 0,65 0,65 | 0,4 0,4 | 0,9 0,9 | 0,045 0,030 | 0,045 0,035 | 0,4 0,4 | 0,1 0,1 | 0,4 0,4 |
| 1.0601 C60 1.1221 C60E | Al | Cu | N | Nb | Ti | Sonstiges |
|---|---|---|---|---|---|---|
| C60 min. C60E min. | ||||||
| C60 max. C60E max. | Cr+Mo+Ni max. 0,63 Cr+Mo+Ni max. 0,63 |
available on request
The processing with the saw is a mechanical processing of the material, which results in a significantly lower unintended deformation and increased hardness for the existing structure, such as the thermal cutting.
Thus, the machined workpiece has a homogeneous structure even at the edge, which does not change in the continuation of the material.
This circumstance allows immediate finishing of the workpiece with milling or drilling . So it is not necessary to anneal the material or make a similar operation beforehand.
Do you have any questions?
We are happy to answer your questions and make you an offer for these and other materials. Contact us now for more information.
Your contact person Andreas Blachowiak+49 (0) 35263-665-37blachowiak@stahlportal.com
Notice: Specifications contained in following data sheet are provided as a description, liability is excluded!
